Herman, Frank, and Zach continue clay surface development. Jim is taking the picture.
This template (white foam-core material) was made to transfer the new hood height from one side to the other.
Here, Frank and Zach have made a template of the top of the passenger compartment from the master side and have flipped it over to the other side to assure that both sides aer symmetrical. The green tape on the hood represents the location of the engine head which is the highest area on the engine. Some clay needed to be added here to assure engine clearance.
